| TP-LINK MC111CS Media Converter (10/100 Ethernet to 100BASE-FX Singlemode Fibre, SC Connector)
TP-LINK MC111CS Media Converter (10/100 Ethernet to 100BASE-FX Singlemode Fibre, SC Connector)
เพิ่มเมื่อ: 2017-03-09 14:00:53.0
แก้ไขล่าสุด: 2019-05-13 13:52:13.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comMC111CS 10/100Mbps RJ45 to 100Mbps single-mode SC fiber Converter, Full-duplex, Tx:1550nm, Rx:1310nm, up to 20Km, switching power adapter, chassis TL-MC1400 rack-mountable(สินค้ารับประกัน 1 ปี)
TP-LINK MC111CS
MC111CS Media Converter (10/100 Ethernet to 100BASE-FX Singlemode Fibre, SC Connector)
- Auto negotiation of 10/100Mbps and auto MID/MID-X for TX port.
- Complies with 802.3u 10/100Base-TX, 100Base-FX standards.
- Provide switch configuration of Half-Duplex / Full-Duplex transfer mode for FX port.
- Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely.
- Adopts WDM technology, transmitting and receiving data on one single Fibre.
- Easy-to-view LED indicators provide status to monitor network activity easily.
- Extend Fibre distance up to 20km.
- External power supply.
Standards and Protocols
-IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Basic Function
- Adopts WDM technology
- Half/Full-Duplex transfer mode for FX port
- Full Duplex Flow Control (IEEE 802.3x)
- Half Duplex Flow Control (Backpressure)
- Link Fault Passthrough and Far End Fault minimise the loss caused by link failure timely
- Extends fiber distance up to 20km
Ports
- 1100M SC port
- 1100M RJ45 port (Auto MDI/MDIX)
WDM TX
- 1550nm
WDM RX
- 1310nm
Network Media 10BASE-T
- UTP category 3, 4, 5 cable (maximum 100m)
- EIA/TIA-568 100Ù STP (maximum 100m)
Network Media 1000BASE-T
- UTP category 5, 5e cable (maximum 100m)
- EIA/TIA-568 100Ù STP (maximum 100m)
Network Media 1000BASE-FX
- Single-mode Fiber
LED Indicators
- PWR, FDX/Col, Link/Act, SPD
Dimensions (W*D*H)
- 3.7*2.9*1.1 in. (94.5*73.0*27.0 mm)
Power Supply
- External Power Adapter
Safety & Emission
- FCC, CE
Environment
- Operating Temperature
- 0°C~40°C (32°F~104°F)
- Storage Temperature
- -40°C~70°C (-40°F~158°F)
- Operating Humidity
- 10%~90% non-condensing
- Storage Humidity
- 5%~90% non-condensing
