| EnGenius EXT1109P 3xGE, 4xGE PoE, 1xGE PD Switch Extender with 1 SFP Port
EnGenius EXT1109P 3xGE, 4xGE PoE, 1xGE PD Switch Extender with 1 SFP Port
เพิ่มเมื่อ: 2025-02-04 19:00:54.0
แก้ไขล่าสุด: 2025-02-04 19:01:01.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comSwitch Extender EnGenius EXT1109P 3xGE, 4xGE PoE, 1xGE PD Switch Extender with 1 SFP Port
EnGenius EXT1109P
Switch Extender EnGenius EXT1109P 3xGE, 4xGE PoE, 1xGE PD Switch Extender with 1 SFP Port
- 1x GE PD PoE port allows the device be powered by PoE.
- 4x GE PoE ports deliver power to other PD devices.
- 3x GE ports for high-speed connections.
- 1x SFP uplink port for bandwidth-intensive applications.
- Zero touch provisioning, centralized cloud configuration and visualized monitoring improve the efficiency of network installation and management.
- Voice VLAN function ensure the security and quality of VoIP traffic.
- Cloud manage switch extenders from anywhere with the EnGenius Cloud App. A Pro license for Cloud To-Go offers more features to fulfill advanced management requirements.
- EnGenius FitXpress (cloud-managed) is a cost-effective management option for Switch Extender series products.
Technical Specifications
Port Standards
802.3u 100Base-TX Ethernet
802.3ab 1000Base-T Ethernet
Network Port – Gigabit Ethernet Ports
8×10/100/1000 Mbps Ports
Network Port – SFP Ports
1x SFP Port
Switching Capacity
18Gbps
Flash Memory
32 MB
PoE Capable Ports
Ports 2- 5 (802.3 af/at)
Total PoE Budget
Power Input: 802.3at Type 2(30W); Power Budget: up to 15W
Power Input: 802.3bt Type 3(60W); Power Budget: up to 40W
Power Input: 802.3bt Type 4(90W); Power Budget: up to 60W
Power Source
PoE PD
Recommend EnGenius PoE adapters (EPA5060GBT, EPA5090GBT),
Optional DC-Jack (100 to 240 VAC, 50/60Hz)
L2 Features
Network Management
EnGenius Cloud
MAC Address Table
8k
Jumbo frame size
10k
Multicast Group
Max 8 groups
QoS-number of Priority Queues Supported
8
QoS Trust Mode
Cos/802.1p
DSCP
CoS/802.1p-DSCP
Bandwidth Control
Port-based bandwidth control (Ingress/Egress)
Web Graphical User Interface (GUI)
LSP(Local status page)
System Time
Time Setting/Daylight saving
Common L2 Features
802.1w Rapid Spanning Tree
Domain Name System (DNS) settings
Multicast Filitering
IGMP Snooping
IGMPv2
IGMP Snooping Fast Leave
Port Statistics
802.1Q VLAN
Voice VLAN
Port-based VLAN
Jumbo Frame
IPv4 Settings
Link Layer Discovery Protocol (LLDP)
Weighted Round Robin Queue(WRR)
Simple Network Time Protocol (SNTP)
SYSLOG
Factory Default
Reboot Switch
Find Me
Dimensions & Weight
Device Dimensions & Weights
Weight: 620g
Length: 9,45” (240 mm)
Width: 4.13” (105 mm)
Height: 1.06” (27 mm)
Package Contents
1x EXT Switch Extender
1x Product Card
1x Wall Mount Kit
1x Adhesive label
1x Rubber Feet Cushion
