PLANET GSW-1600HP 16-Port 10/100/1000Mbps 802.3at PoE+ Gigabit Unmanaged Switch

จำนวนครั้งที่เปิดดูสินค้า : 7919 | ความคิดเห็น: 0

PLANET GSW-1600HP 16-Port 10/100/1000Mbps 802.3at PoE+ Gigabit Unmanaged Switch

เพิ่มเมื่อ: 2014-11-30 19:38:53.0

แก้ไขล่าสุด: 2023-04-28 18:32:34.0

เบอร์โทรติดต่อ: 062-5193997 , 02-4582949

อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
GSW-1600HP 16-Port 10/100/1000Mbps IEEE 802.3af/IEEE 802.3at PoE Gigabit Unmanaged Switch (สินค้ารับประกัน 3 ปี)

12900.00 บาท

PLANET GSW-1600HP

GSW-1600HP 16-Port 10/100/1000Mbps 802.3at PoE+ Gigabit Unmanaged Switch

Centralized Power Management for Gigabit Ethernet PoE Networking
To facilitate high power PoE network applications with Gigabit speed transmission, the GSW-1600HP 16-Port Gigabit High Power over Ethernet Switch features high performance Gigabit IEEE 802.3af PoE (Up to 15.4W) and IEEE 802.3at High-Power PoE (Up to 30.8W) capabilities on all ports. By offering reliable switching technology and advanced networking features, the GSW-1600HP optimizes the installation and power management of network devices such as wireless access points (AP), VoIP phones, and security video cameras. It also eliminates time and cost of deployment by integrating power and data switching into one unit, and freeing network devices from restrictions of power outlet locations and the additional AC wiring.

Perfect Integrated Solution for PoE IP Surveillance
The GSW-1600HP brings an ideal secure surveillance system at a lower total cost. The GSW-1600HP provides 16 10/100/1000Mbps 802.3at PoE port able to feed sufficient PoE power for 16 IEEE 802.3af / IEEE 802.3at PoE IP cameras at the same time. It is also able to connect with one 16-Channel NVR or two 8-Channel NVR systems, uplink to backbone switch and the monitor center. With such high performance switch architecture, the recorded video files from the PoE IP Cameras can be saved in the NVR system via which the administrators can control and monitor the surveillance images both in the local LAN and the remote sites.

Energy-Saving Design
The GSW-1600HP uses new engine that incorporates two advanced Green Networking technologies:
　■ Idle Mode Link Down power saving
　■ Intelligent Scales Power based on cable length
The Idle mode Link Down power saving of the GSW-1600HP complies with Pre-IEEE 802.3az Energy Efficient Ethernet (EEE) standard to automatically lower power for a given port when it is not linked. The Intelligent Scales Power technology actively determines the appropriate power level based on the cable length. When connecting to the GSW-1600HP with Ethernet cable shorter than 20m, a device can obtain maximum power saving because the GSW-1600HP would automatically detect the Ethernet cable length and reduce power usage. The connected device can substantially reduce overall power consumption, which makes a significant contribution to energy saving.

Easy Installation & Cable Connection
Providing data transfer and High Power PoE in one unit, the GSW-1600HP is able to reduce the need of extension cables and dedicated electrical outlets on the wall, ceiling or any unreachable place. It helps to lower the installation costs and simplify the installation effort. All RJ-45 copper interfaces of the GSW-1600HP supports 10/100/1000Mbps auto-negotiation for optimal speed detection through RJ-45 Category 6, 5 or 5e cables. It also supports standard auto-MDI/MDI-X that can detect the type of connection to any Ethernet device without requiring special straight or crossover cables.

Applications

Department / Workgroup PoE Network
Providing 16-port PoE in-line power interfaces, the GSW-1600HP can easily build a power centrally-controlled IP phone system, IP Camera system and Wireless AP group for the enterprise. Cameras can be installed around the corner in the company or campus for surveillance demands. Without the power-socket limitation, the GSW-1600HP makes the installation of cameras easier and more efficient.

Features

Interface

16-Port 10/100/1000Mbps Gigabit Ethernet RJ-45 ports
Each port supports 52V DC power to PoE Powered Device

Power over Ethernet

Complies with IEEE 802.3af / IEEE 802.3at Power over Ethernet
Up to 16 IEEE 802.3af / IEEE 802.3at devices powered
Supports PoE Power up to 30 Watts for each PoE port
Auto detect powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m

Switching

Hardware based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Flow control for full duplex operation and back pressure for half duplex operation
Integrates address look-up engine, supporting 8K absolute MAC addresses
9K Jumbo Frame supports at all speed (10/100/1000Mbps)
Automatic address learning and address aging
Supports Pre-Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)

Hardware
